Technical Specifications
MIL-PRF-23699F | SPECIFICATIONS | MIL-PRF-23699F | MIL-PRF-23699F | |
Oil Type | Synthetic Ester | Synthetic Ester | Synthetic Ester | |
Kinematic Viscosity mm²/s | 100 °C | 4.90 to 5.40 | 5 | 5.24 |
– | ||||
40°C | 23 | 25.3 | 26.71 | |
11000 | ||||
-40°C | 13000 max | 0 | 11000 | |
Flash Point | °C | 246 min | 252 | 252 |
Pour Point | °C | -54 max | -60 | -60 |
TAN | mg KOH/g | 1 max | 0.06 | 0.22 |
Evaporation Loss 6.5 hrs/204°C | %m | 10.0 max | 4.2 | 2 |
Foaming | – | – | Pass | Pass |
Corrosive and Oxidative Stability | 72 hrs / 204°C | – | – | – |
Viscosity Change % | – | – | 1.54 | 1.02 |
Contamination mg/100ml | – | – | 7 | 0.55 |
